SunnySky X Series V3 X7025 V3 40CC Equivalent Motors
[TABS]OVERVIEW
| Motor Model / KV | 7025KV160 | 7025KV190 |
|---|---|---|
| Stator/Rotor Poles | 24N22P | 24N22P |
| Internal resistance | 22.8mΩ | 15.06mΩ |
| Motor size | Motor length：67mm | Motor length：67mm |
| Shaft diameter | 10mm | 10mm |
| AWG | Leading wire | Leading wire |
| Motor weight(wire included) | 780g | 785g |
| Motor weight(wire excluded) | ||
| Rated operational voltage | 37.89V | 38.05V |
| No-load current | 49.993A | 85.216A |
| Maximum continuous power | 5400W | 5800W |
| Maximum continuous current | 120A/30s | 127A/30s |
| ESC recommended use | 130A | 130A |
| Propeller size recommended use | 2110／2210／2214／2410 | 21*10／22*10／22*14 |
[/TABS]
$249.99
SunnySky X Series V3 X7025 V3 40CC Equivalent Motors—
$249.99
More Images
SunnySky X Series V3 X7025 V3 40CC Equivalent Motors
[TABS]OVERVIEW
| Motor Model / KV | 7025KV160 | 7025KV190 |
|---|---|---|
| Stator/Rotor Poles | 24N22P | 24N22P |
| Internal resistance | 22.8mΩ | 15.06mΩ |
| Motor size | Motor length：67mm | Motor length：67mm |
| Shaft diameter | 10mm | 10mm |
| AWG | Leading wire | Leading wire |
| Motor weight(wire included) | 780g | 785g |
| Motor weight(wire excluded) | ||
| Rated operational voltage | 37.89V | 38.05V |
| No-load current | 49.993A | 85.216A |
| Maximum continuous power | 5400W | 5800W |
| Maximum continuous current | 120A/30s | 127A/30s |
| ESC recommended use | 130A | 130A |
| Propeller size recommended use | 2110／2210／2214／2410 | 21*10／22*10／22*14 |
[/TABS]
Product Information
Product Information
Shipping & Returns
Shipping & Returns
Description
[TABS]OVERVIEW
| Motor Model / KV | 7025KV160 | 7025KV190 |
|---|---|---|
| Stator/Rotor Poles | 24N22P | 24N22P |
| Internal resistance | 22.8mΩ | 15.06mΩ |
| Motor size | Motor length：67mm | Motor length：67mm |
| Shaft diameter | 10mm | 10mm |
| AWG | Leading wire | Leading wire |
| Motor weight(wire included) | 780g | 785g |
| Motor weight(wire excluded) | ||
| Rated operational voltage | 37.89V | 38.05V |
| No-load current | 49.993A | 85.216A |
| Maximum continuous power | 5400W | 5800W |
| Maximum continuous current | 120A/30s | 127A/30s |
| ESC recommended use | 130A | 130A |
| Propeller size recommended use | 2110／2210／2214／2410 | 21*10／22*10／22*14 |
[/TABS]
